LED Spot 100 IC / LED Spot HP IC
The LED Spot 100 IC / HP IC has been developed for all applications requiring a highly intensive UV irradiance over a large area. The LED assembly, as well as an electronic power control, guarantee high intensity and homogenous distribution of light. The recognition of LED-malfunction and a comprehensive monitoring function provide very high process stability. So, especially in fully automated production lines, repeatable results can be realized even in shortest cycle times.
The typical service life of a LED is longer than 20.000 hours***. The LED Spot 100 IC / HP IC can be switched on and off as often as necessary. It does not require a warm-up or cooling phase.
The emitted wavelengths are available in 365/385/395/405/ 460 nm +/- 10 nm. This allows to adapt the LED Spot to the existing application.
The square light-emitting aperture has a size of about 100 mm x 100 mm. Depending on the required intensity/homogeneity it can be increased considerably by changing the distance to the substrate. The optimized housing design means the devices are now stackable with only minimal gaps. An integrated fan provides adequate cooling even for continuous operation.
The new LED Spot 100 HP IC is the most powerful model. At 405 nm wavelength 2.200 mW / cm2 guarantee reliable and fast curing.
Download LED Spot 100 IC / LED Spot HP IC Technical Data Sheet
